Socket Button Head Cap Screw

Products

Socket Button Head Cap Screw

  • Controlled mechanical properties for higher strength
  • Uniform & uninterrupted grain flow for greater strength.
  • Smooth radiuses head ensures easy handling to the user.
  • Uniform socket depth for accurate key fit & higher torque.
  • Smooth fillet radius to withstand head soundness.
  • High grade alloy steel for good strength & wear resistance.
  • Formed threads with improved root radius provide greater strength to threads.
  • Controlled hex socket for maximum wrenching strength.
  • Controlled concentricity in totality to create a high resistance to lateral movements

    • Socket Button Head Cap Screw Dimensions
    Diam Pitch a j k
    d mm Max Nom Max
    M3 0.50 5.70 2.00 1.65
    M4 0.70 7.60 2.50 2.20
    M5 0.80 9.50 3.00 2.75
    M6 1.00 10.50 4.00 3.30
    M8 1.25 14.00 5.00 4.40
    M10 1.50 17.50 6.00 5.50
    IPS Range of Socket Button Head
    Product Range Grade Standard Raw Material
    Button Head M3 to M10 12.9 DIN9427 & ISO7380 Alloys Steel
    Button Head Special Items As per customer drawings only
